Section 4: Using the Model 9100: AC Voltage Function 4.4-3
Final Width = 215mm
4.4.3 Screen Keys
4.4.3.1 Bottom Screen Keys
V Selects DC Voltage Function when AC Voltage Function is active.
V Selects AC Voltage Function when DC Voltage Function is active.
∆% Adds the 'AC Voltage Deviation' value to the display presentation.
Refer to paras 4.4.3.3.
WAVE Gives access to change the waveshape of the output voltage.
FORM Refer to paras 4.4.3.4.
∆Φ Gives access to the phase-locking facility.
Refer to paras 4.4.3.5.
4.4.3.2 Right Side Screen Keys
A. Digit Edit Facility Keys operate on the value marked by the cursor.
X
10 Multiplies the marked value by ten.
÷
10 Divides the marked value by ten.
± Reverses the polarity of the marked value. The ± key is only available
when the cursor is marking the Deviation value
ZERO Sets the marked value to zero.
ZERO
is available only when the cursor
is marking the Output value.
B. Direct Edit Facility Right side screen keys operate on the value in the edit box,
and acting in place of the ↵ key, exit from Direct Edit back
to Digit Edit; then set the value as evaluated in the box.
i. Output Value
mV Evaluates the number in the box in Millivolts.
V Evaluates the number in the box in Volts.
kV Evaluates the number in the box in Kilovolts.
ii. Frequency
Hz Evaluates the number in the box in Hertz.
kHz Evaluates the number in the box in Kilohertz.
iii. Deviation Value
% Evaluates the number in the box in Percentage Deviation.
The Deviation value is limited to ±10% of the Output value.
All values are set into the highest resolution available to their magnitude.
