4.5 DC Current Function — Operation
4.5.1
This sub-section is a guide to the use of the 9100 for generating a required DC Current
output. The following topics are covered:
4.5.2 Selection of DC Current Function.
4.5.2.1 'A' Key.
4.5.2.2 Default Settings.
4.5.3 Screen Keys.
4.5.3.1 Bottom Screen Keys.
4.5.3.2 Right Side Screen Keys.
4.5.3.3 Introducing Deviation and Offset Values.
4.5.4 Value Editing.
4.5.4.1 Output, Offset and Deviation.
4.5.5 Crossing Thresholds.
4.5.5.1 Current Resolution Thresholds.
4.5.5.2 Hardware Configurations.
4.5.6 Select Output
4.5.6.1 Normal Output.
4.5.6.2 Auxiliary Output.
4.5.6.3 Option 200: 10- and 50-Turn Current Coils.
4.5.6.4 10-Turn Coil.
4.5.6.5 50-Turn Coil.
4.5.7 DC Current Routines for Calibrating UUTs.
4.5.7.1 Interconnections
4.5.7.2 Using the 9100 as a Fixed Source
4.5.7.3 Using the 9100 as an Adjustable Source
In this sub-section, we deal with the full range of DCI facilities, in a concise way. For
those who require more detailed instructions for manipulating the front panel controls,
the DC Voltage function was used as an example for the general familiarization tutorials
in Section 3, and this may provide an introduction to the function.
