Section 4: Using the Model 9100: AC Current Function 4.6-1
Final Width = 215mm
4.6 AC Current Function — Operation
4.6.1
This sub-section is a guide to the use of the 9100 for generating a required AC Current
output. The following topics are covered:
4.6.2 Selection of AC Current Function.
4.6.2.1 'A' Key.
4.6.2.2 Default Settings.
4.6.3 Screen Keys.
4.6.3.1 Bottom Screen Keys.
4.6.3.2 Right Side Screen Keys.
4.6.3.3 Introducing Deviation Values.
4.6.3.4 Selecting Other Waveshapes.
4.6.3.5 Phase-Locking Facilities.
4.6.4 Value Editing.
4.6.4.1 Output and Deviation.
4.6.4.2 Frequency Editing.
4.6.4.3 'Out of Range'.
4.6.5 Crossing Thresholds.
4.6.5.1 AC Current Resolution Thresholds.
4.6.5.2 Frequency Resolution Thresholds.
4.6.5.3 Hardware Configurations.
4.6.6 Select Output
4.6.6.1 Normal Output.
4.6.6.2 Auxiliary Output.
4.6.6.3 Option 200: 10- and 50-Turn Current Coils.
4.6.6.4 10-Turn Coil.
4.6.6.5 50-Turn Coil.
4.6.7 Amp-Hertz Limits.
4.6.7.1 Amp-Hertz Profile
4.6.8 AC Current Routines for Calibrating UUTs.
4.6.8.1 Interconnections
4.6.8.2 Using the 9100 as a Fixed Source
4.6.8.3 Using the 9100 as an Adjustable Source
In this sub-section, we deal with the full range of ACI facilities, in a concise way. For
those who require more detailed instructions for manipulating the front panel controls,
the DC Voltage function was used as an example for the general familiarization tutorials
in Section 3.
