4.6-2 Section 4: Using the Model 9100: AC Current Function
Final Width = 215mm
4.6.2 Selection of AC Current Function
(Manual Mode selected)
4.6.2.1 'A' Key
Current is selected by pressing the
'A' key at the top right of the 'CALIBRATION SYSTEM'
panel.
4.6.2.2 Default Settings
At power-on the system defaults to DC Voltage function. Each time the
'A' key is pressed,
the system defaults into DC Current function.
If DC Current is already active, then the AC Current menu screen is opened by pressing
the
A screen key on the bottom row.
Whenever the AC Current menu screen is opened, except on recovery from a standby
period, it will appear with the following default settings:
TODAYS DATE TIME
x
÷
A
A
∆ Φ
∆ %
WAVE
FORM
.
A
.
kHz
Peak 1.41421 V
Mean 0.90032 V
ZERO
SELECT
OUTPUT
