Section 4: Using the Model 9100: Conductance Function 4.8-1
Final Width = 215mm
4.8 Conductance Function — Operation
4.8.1
This sub-section is a guide to the use of the 9100 for generating a required Conductance
output. The following topics are covered:
4.8.2 Selection of Conductance Function.
4.8.2.1 'Aux' Key.
4.8.2.2 Default Settings.
4.8.3 Screen Keys.
4.8.3.1 Bottom Screen Keys.
4.8.3.2 Right Side Screen Keys.
4.8.3.3 Introducing Deviation and Offset Values.
4.8.4 Value Editing.
4.8.4.1 Output, Offset and Deviation.
4.8.5 Crossing Thresholds.
4.8.5.1 Conductance Resolution Thresholds.
4.8.5.2 Hardware Configurations.
4.8.5.3 Configuration for Conductance Measurement in UUTs.
4.8.5.4 Configuration for Conductance Function in the 9100.
4.8.5.5 4-Wire Connections for Conductance Function.
4.8.5.6 Two-Wire Connection.
4.8.5.7 Spans of Source Currents.
4.8.6 Conductance Routines for Calibrating UUTs.
4.8.6.1 Interconnections.
4.8.6.2 Using the 9100 as a Fixed Source.
4.8.6.3 Using the 9100 as an Adjustable Source.
In this sub-section, we deal with the full range of Conductance facilities, in a concise way.
For those who require more detailed instructions for manipulating the front panel
controls, the DC Voltage function was used as an example for the general familiarization
tutorials in Section 3, and this may provide an introduction to the function.
