4.8-2 Section 4: Using the Model 9100: Conductance Function
Final Width = 215mm
4.8.2 Selection of Conductance Function
(Manual Mode selected)
4.8.2.1 'Ω' Key
Conductance is associated with the 'Ohms' function. The Ohms menu screen is selected
by pressing the 'Ω' key at the right of the 'CALIBRATION SYSTEM' panel. Conductance
is selected by pressing the
Ω
screen key on the bottom row.
4.8.2.2 Default Settings
At power-on, the system defaults into DC Voltage function. Each time the
'Ω' key is
pressed, the system defaults into Ohms function.
Whenever the Conductance menu screen is opened by pressing the
Ω
screen key on the
Ohms menu screen, except on recovery from a standby period, it will appear with the
following default settings:
TODAYS DATE TIME
x
∆
÷
U
U
T
i
.
µS
Ω
CHANGE
CURRENT
4 WIRE
Ω
Ω
