Section 4: Using the Model 9100: Frequency Function 4.9-1
Final Width = 215mm
4.9 Frequency Function — Operation
4.9.1
This sub-section is a guide to the use of the 9100 for generating a required Frequency
output. The following topics are covered:
4.9.2 Selection of Frequency Function.
4.9.2.1 'Hz' Key.
4.9.2.2 Default Settings.
4.9.3 Screen Keys.
4.9.3.1 Bottom Screen Keys.
4.9.3.2 Right Side Screen Keys.
4.9.4 Value Editing.
4.9.4.1 Editing Output Frequency.
4.9.4.2 Editing High and Low Voltage Levels.
4.9.5 Crossing Thresholds.
4.9.5.1 Frequency Resolution Thresholds.
4.9.5.2 Analog Hardware Configurations.
4.9.6 Frequency Routines for Calibrating UUTs.
4.9.6.1 Interconnections
4.9.6.2 Using the 9100 as a Fixed Source
4.9.6.3 Using the 9100 as an Adjustable Source
In this sub-section, we deal with the full range of 'Hz' facilities, in a concise way. For those
who require more detailed instructions for manipulating the front panel controls, the DC
Voltage function was used as an example for the general familiarization tutorials in
Section 3.
