High and Low Signal Level Switching
The effect of changing the values, appearing in the High and Low Level positions on the
screen, is to alter the voltages between which the rectangular output waveform switches.
High and Low Signal Level Limits
The high and low signal levels are respectively the most-positive and most-negative
excursions of the output signal, and cannot be set outside the following limits:
In addition, the High Level cannot be set equal to or more negative than the Low Level.
Frequency Signal Span of Values
Span Level
000.500Hz to 1.00000kHz High -29.98 V to +30.00 V
Low -30.00 V to +29.98 V
1.00001kHz to 10.0000MHz High -05.99 V to +06.00 V
Low -06.00 V to +05.99 V
