Section 4: Using the Model 9100: Capacitance Function 4.13-1
Final Width = 215mm
4.13 Capacitance Function — Operation
4.13.1
This sub-section is a guide to the use of the 9100 for generating a required Capacitance
output. The following topics are covered:
4.13.2 Selection of Capacitance Function.
4.13.2.1 'Aux' Key.
4.13.2.2 Default Settings.
4.13.3 Screen Keys.
4.13.3.1 Bottom Screen Keys.
4.13.3.2 Right Side Screen Keys.
Note: Internal Compensation.
4.13.3.3 Introducing Deviation and Offset Values.
4.13.4 Value Editing.
4.13.4.1 Output, Offset and Deviation.
4.13.5 Crossing Thresholds.
4.13.5.1 Capacitance Resolution Thresholds.
4.13.5.2 Hardware Configurations.
4.13.5.3 Configuration for Capacitance Measurement in UUTs.
4.13.5.4 Configuration for Capacitance Function in the 9100.
4.13.5.5 4-Wire Connections for Capacitance Function.
4.13.5.6 Two-Wire Connection.
4.13.5.7 Spans of Source Currents.
4.13.6 Capacitance Routines for Calibrating UUTs.
4.13.6.1 Interconnections.
4.13.6.2 Using the 9100 as a Fixed Source.
4.13.6.3 Using the 9100 as an Adjustable Source.
In this sub-section, we deal with the full range of Caapacitance facilities, in a concise way.
For those who require more detailed instructions for manipulating the front panel
controls, the DC Voltage function was used as an example for the general familiarization
tutorials in Section 3, and this may provide an introduction to the function.
