4.17 Logic-Levels Function — Operation
4.17.1
This sub-section is a guide to the use of the 9100 for generating test DC Voltage levels
for TTL, CMOS and ECL logic. The following topics are covered:
4.17.2 Selection of Logic-Levels Function.
4.17.2.1 'Aux' Key.
4.17.2.2 Default Settings.
4.17.3 Screen Keys.
4.17.3.1 Bottom Screen Keys.
4.17.3.2 Right Side Screen Keys.
4.17.4 Value Editing.
4.17.4.1 DC Voltage Values.
4.17.5 Crossing Thresholds.
4.17.5.1 Logic-Level Resolution.
4.17.5.2 Hardware Configurations.
4.17.6 'Logic-Levels' Routines for Calibrating UUTs.
4.17.6.1 Interconnections
4.17.6.2 Using the 9100 as a Fixed Source
4.17.6.3 Using the 9100 as an Adjustable Source
In this sub-section, we deal with the full range of 'Logic-Levels' facilities, in a concise
way. For those who require more detailed instructions for manipulating the front panel
controls, the DC Voltage function was used as an example for the general familiarization
tutorials in Section 3.
