4.18-8 Section 4: Using the Model 9100: Insulation/Continuity Function (Option 135)
2. There is no CHANGE CURRENT key. The internal dynamic range settings of the
Model 9100 hardware have been optimally configured for continuity measurements.
Correspondingly, there is no bargraph indication of the UUT current setting as this is
automatically adjusted by the Model 9100.
3. The output current of the UUT is displayed in the upper right-hand corner of the
screen. This is for confirmation that the output current of the continuity tester
complies with its minimum current specification. This display defaults to X.XXXX
xA when no test is being conducted.
Refer to sections 4.7.5.4 and 4.7.5.5 for a more detailed explanation of the operation and
configuration of the Active Ohms circuit.
