Section 4: Using the Model 9100: AC Harmonics Function 4.21-3
Final Width = 215mm
4.21.2 Selection of AC Harmonics Function
(Manual Mode selected) Entry is via the AUX key at the bottom right of the
‘CALIBRATION SYSTEM’ panel, followed by the POWER softkey if one of the
oscilloscope calibration options (Option 250 or Option 600) is fitted.
Note that the 9105 Lead mat must NOT be used.
Figure 4.21.2 - the Auxiliary Function selection screen.
date time
W
Ω
LOGIC°C
The display on
these areas of the
screen will depend
on the options fitted
to the Model 9100
W
W
AC Harmonics is selected by pressing the
W vertical softkey.
