3-18 Section 3: Model 9100 Controls: Modes of Operation
Final Width = 215mm
TODAYS DATE TIME
TODAYS DATE TIME
TODAYS DATE TIME
3.3.2.13 'CERT DETAILS'
1. For access to allow the certificate
formatting to be altered, press the
CERT DETAILS screen key on
the 'MORE' 'Present Settings'
screen
Results Certificates
In Procedure mode, three styles of
printed certificate are available:
Style 1
This provides full information about
each point tested, including applied
and target values, spec limits and UUT
error, % error pass/fail and test
uncertainty ratio between 9100 and
UUT.
Style 2
This is a shorter form of certificate,
showing only the applied and target
values, and the 9100 absolute
uncertainty.
Style 3
This certificate is similar to Style 1,
and has been added to accommodate
the wider spec limits encountered
during oscilloscope calibration,
expressed in percentages rather than
ppm.
Users are given the facility, in
Configuration mode, to change the style
of certificate to be printed.
2. This transfers to what we shall refer to as a 'CERT DETAILS' screen (see below),
which allows users to design a certificate by adjusting or selecting characteristics via
screen keys on the right (refer to paras 3.3.2.14).
3. The EXIT screen key reverts to the 'MORE' - 'Present Settings' screen.
Configuration
EXIT
The certificate type is indicated
by the highlight.
Use the softkeys to select
another.
STYLE 1
STYLE 2
2. This transfers to 'The certificate
type' screen, which allows the
style of certificate to be selected
3. Press the key on the right which
represents the required style of
certificate
4. Press the EXIT screen key to
revert to the CERT DETAILS
screen
3.3.2.14 'CERT STYLE'
1. For access to select the certificate
style, press the CERT STYLE
screen key on the 'CERT
DETAILS' screen
Configuration
EXIT
Present settings
Certificate style Style 1
Page length 66 lines
Header size Ø lines
Footer size 1 lines
Appended message XXX XXX...
APPEND
MESSAGE
FOOTER
SIZE
HEADER
SIZE
CERT
STYLE
STYLE 3
Configuration
Ser. No. XXXXXX Rev. XXX
Present Settings:
Certificate Style Style 1
Engineers Notes Disabled
Fluke Lead Cap 28.50 pF
User Lead Cap 0.00 pF
EXIT
NEW
PASSWRD
CERT
DETAILS
ENG
NOTES
WFLUKE
LEAD
CAP
USER
LEAD
CAP
PAGE
LENGTH
LAB
DETAILS
To Next Page
