4.3-2 Section 4: Using the Model 9100: DC Voltage Function
Final Width = 215mm
x
∆
÷
V
V
V
ZERO
+
.
V
±
4.3.2 Selection of DC Voltage Function
(Manual Mode selected)
4.3.2.1 'V' Key
Voltage is selected by pressing the
'V' key at the top right of the 'CALIBRATION SYSTEM'
panel.
4.3.2.2 Default Settings
At power-on and each time the
'V' key is pressed, the system defaults into DC Voltage
function.
If AC Voltage is already active, then the DC Voltage menu screen is opened by pressing
the
V screen key on the bottom row.
Whenever the DC Voltage menu screen is opened, except on recovery from a standby
period, it will appear with the following default settings:
