Section 4: Using the Model 9100: DC Voltage Function 4.3-3
Final Width = 215mm
4.3.3.1 Bottom Screen Keys
V Selects DC Voltage Function when AC Voltage Function is active.
V Selects AC Voltage Function when DC Voltage Function is active.
∆ Accesses the 'Percentage Deviation' and 'DC Voltage Offset' displays
to add to the screen presentation. Refer to paras 4.3.3.3 and 4.3.4.1.
4.3.3.2 Right Side Screen Keys
A. Digit Edit Facility Keys operate on the value marked by the cursor.
X
10 Multiplies the marked value by ten.
÷10 Divides the marked value by ten.
± Reverses the polarity of the marked value.
ZERO Sets the marked value to zero.
B. Direct Edit Facility Right side screen keys operate on the value in the edit box,
and acting in place of the ↵ key, exit from Direct Edit back
to Digit Edit; then set the value as evaluated in the box.
i. Output Value and Offset Value
mV Evaluates the number in the box in Millivolts.
V Evaluates the number in the box in Volts.
kV Evaluates the number in the box in Kilovolts.
ii. Deviation Value
% Evaluates the number in the box in Percentage Deviation.
The Deviation value is limited to ±10% of the Output value.
Output and Offset values are set into the same resolution. All values are set into the
highest resolution available to their magnitude.
4.3.3 Screen Keys
