US-72 Original User Guide | Impulse Evo pedelec Version 2
7.2 Technical Data
* With a 4 A charger up to 95% of
full charge capacity
** Measured at the lowest assist
mode, under optimal conditions
and with a fully charged battery
of the highest capacity.
Type
15 Ah 17 Ah
Position
Seat post Seat post
Nominal capacity
14.25 Ah 16.75 Ah
Nominal voltage
36 V 36 V
Power
520 Wh 603 Wh
Weight
6.88 lbs 7.02 lbs
Charging cycles
1100 full cycles 1100 full cycles
Charging time*
Approx. 3.5 hours Approx. 4 hours
Cell
Li-ion Li-ion
Range**
111 mi. 127 mi.
Permitted ambient temperature
range during operation
14 to 104 °F 14 to 104 °F
Permitted charging temperature
32 to 104 °F 32 to 104 °F
Storage temperature
14 to 122 °F 14 to 122 °F
Recommended storage
temperature
65 to 74 °F 65 to 74 °F
7.3 Overview and basic functions
SpecicationplateDisplay panel Charging socket
Discharging socket
Protective cap for
charging socket
– ve pole + ve pole
