Original User Guide | Impulse Evo pedelec Version 2 US-75
3. Push the battery forwards and
upwards into the docking station until
the locking mechanism engages.
4. Remove the battery key from the
battery lock. The battery is now
locked.
NOTICE
Werecommendyouremovethekeytopreventitbreakingoand
getting lost.
For 3. Insert the battery into the docking
station
For 4. Lock battery
7.3.3 Unlocking and removing the battery
1. Gripthebatteryrmly,putthekeyinto
the lock and turn clockwise. Hold the
key. The battery is unlocked.
2. Grip the battery and tip it sideways
out of the docking station.
NOTICE
Graspthebatteryrmly, so that it does not fall out of your hand. It
can be damaged if you drop it.
For 1. Unlock battery
For 2. Remove battery
