Focus IMPULSE EVO PEDELEC - Page 74

US-74 Original User Guide | Impulse Evo pedelec Version 2
7.3.1.3 Sleep mode
To prevent a total discharge, the battery management
system (BMS) switches to sleep mode. After two days your
battery will revert to sleep mode irrespective of the charge
level.
To wake from sleep mode
1. Press the battery button for one second. The following appears:
Display Description

Therst,second,third,fourthandfthLEDscomeoninorderandthenall
goo.
2. The battery has now "woken up".
If no LED blinks, or all 5 LEDs blink repeatedly, the battery
may be defective  7. Battery, Page US-70.
Initiating sleep mode
1. Press the battery button twice. The following appears:
Display Description
TherstandfthLEDsashtwice.
2. The battery is now in sleep mode.
7.3.2 Inserting and locking the battery
NOTICE
Graspthebatteryrmly,so that it does not fall out of your hand. It
can be damaged if you drop it.
One-key system: The same key can be used for both the bike
and battery locks (where fitted).
1. Hold the battery in front of the docking
stationatangleof80˚,slightlytilted
to the left.
2. Insert the battery nibs into recesses
provided.
For1.
Hold in front of docking station
Battery catches
and dents
For 2. Battery catches in dents
