FUSE SPECIFICA
TION CHART
Engine junction box
E79716
19
6
7
8
10
9
12
1
1
14
13
16
15
29
36
28
34
35
33
22
25
32
5
4
3
2
1
20
17
18
24
21
30
31
23
26
27
Circuits protected
Ampere
rating
Fuse
Cooling fan
50
1
Power steering
80
2
Passenger junction box supply 1
60
3
Passenger junction box supply 2
60
4
Climate control
80
5
Auxiliary heater (diesel only)
60
6
ABS, stability control pump
30
7
ABS, stability control valves
20
8
Powertrain control module
20
9
179
Fuses
180
182
