Ford C-MAX - Engine Compartment Overview - 1.8 L Duratorq-Tdci (Lynx) Diesel

ENGINE COMPARTMENT OVERVIEW - 1.8L
DURATORQ-TDCI (LYNX) DIESEL
E78892
I
FEDCBA
H G
Screen washer fluid reservoir
*
: See Washer fluid check (page
203).
A
Engine coolant reservoir
*
: See Engine coolant check (page 201).
B
Brake and clutch fluid reservoir (right-hand drive)
*
: See Brake and
clutch fluid check (page 202).
C
Engine oil filler cap
*
: See Engine oil check (page 200).
D
