WINDSCREEN WIPERS
E71012
A
B
C
D
Single wipe
A
Intermittent wipe or
autowipers
B
Normal wipe
C
High speed wipe
D
Intermittent wipe
E71013
B
C
A
Long wipe interval
A
Intermittent wipe
B
Short wipe interval
C
The rotary control can be used to
adjust the intermittent wipe interval.
Autowipers
E71014
B
59
Wipers and washers
60
62
