Brake lamp P21 wattA
Direction indicator PY21 watt
(orange)
B
Reversing lamp P21 wattC
Rear fog lamp/tail lamp
P21/4 Watt
D
Note:
Vehicles may not have a tail
lamp if an LED board is fitted. The
LED board is not a serviceable item,
please consult your dealer if this fails.
Turn the bulb anticlockwise under
slight pressure and remove it.
Replace the bulb.
Install in the reverse order. After
installation, check that the lights
operate correctly.
Central brake lamp
Consult an expert.
Number plate lamp
5 watt festoon
Loosen the two screws, and remove
the lamp assembly.
Install in the reverse order.
Interior and reading lamps
Switch off the lights.
Insert a flat-bladed screwdriver into
the recess between the body of the
unit and the lens at the opposite side
to the switches. Gently prise out the
lens a short way. Take hold of the
side of the lens and lift it off the unit.
81
Lighting
