Ford C-MAX Owner's Handbook

Dimension in mm
(inches)
Dimension descriptionItem
103 (4.1)
Bumper – end of tow ball - vehicle with fixed
tow ball
A
146 (5.7)
Bumper – end of tow ball - vehicle with
detachable tow ball
A
32 (1.3)Attachment point – centre of tow ballB
898 (35.4)
Wheel centre – centre of tow ball - vehicle
with fixed tow ball
C
941 (37.0)
Wheel centre – centre of tow ball - vehicle
with detachable tow ball
C
517 (20.4)Centre of tow ball – side memberD
1034 (40.7)Inner side of side memberE
400 (15.7)
Centre of tow ball – centre 1. attachment point
- vehicle with fixed tow ball
F
443 (17.4)
Centre of tow ball – centre 1. attachment point
- vehicle with detachable tow ball
F
699 (27.5)
Centre of tow ball – centre 2. attachment
point - vehicle with fixed tow ball
G
742 (29.2)
Centre of tow ball – centre 2. attachment
point - vehicle with detachable tow ball
G
230
Technical specifications
