Antenna PositionsMaximum output power
Watt (Peak RMS)
Frequency
Band MHz
3, 850 W1 – 30
2, 350 W30 – 54
1, 2, 3, 4, 550 W68 – 87.5
1, 2, 3, 4, 550 W142 – 176
1, 2, 3, 4, 550 W380 – 512
1, 2, 3, 4, 5 (6
1
, 7
1
)10 W (2 W
1
)
806 – 940
210 W1200 – 1400
1, 2, 3, 4, 5 (6
1
, 7
1
)10 W (1 W
1
)
1710 – 1885
1, 2, 3, 4, 5 (6
1
, 7
1
)10 W (1 W
1
)
1885 – 2025
All positions0.1 W2400 – 2500
1
Only for GSM/3G cellular phones, with a patch antenna installed inside of the
front windscreen.
Note:
After the installation of RF
transmitters, check for disturbances
from and to all electrical equipment
in the vehicle, both in the standby and
transmit modes.
Check all electrical equipment:
•
with the ignition ON
•
with the engine running
•
during a road test at various
speeds.
Check that electromagnetic fields
generated inside the vehicle cabin by
the transmitter installed do not
exceed human exposure limits
specified in EU directive 2004/40/EC.
263
Appendices
