PV series Solar Pumping Inverter
- 23 -
（Fmax)
F01.09
Upper Limit
Frequency(Fup)
Fdown～Fmax
50.00Hz
×
F01.10
Lower Limit
Frequency(Fdown)
0.00～Fup
0.00Hz
×
F01.11
Given frequency lower
than the frequency
control of lower limit
0：Run by the lower frequency
0
×
1：After running time of lower
limit frequency, it will run on
speed of 0.
F01.12
Running time of lower
limit frequency
0.0～6000.0s
60.0s
×
F02 Group: Control of Run/Stop
F02.00
Command Source
Selection of Run/Start
0：Operation Panel（LED off）
1
×
1：External Terminal（LED on）
2：Computer Communications
（LED flash）
F02.12
Stop mode
0: Ramp to stop
0
×
1: Coast to stop
F03 Group: Acceleration/Deceleration Time
F03.00
Acceleration Time 1
0.0～6000.0s
15.0s
△
F03.01
Deceleration Time 1
0.0～6000.0s
1.0s
△
F04 Group: Digital Input Terminals
F04.00
Terminal DI1 Function
Selection
0:No function
1:Running forward (FWD)
2:Running reverse (REV)
3:Three-wire control
4:JOG forward
5:JOG reverse
6:Coast to stop
7:Fault reset (RESET)
8:Running suspended
9:External fault input
10:Terminal UP
11:Terminal DOWN
12:UP/DOWN (including ∧/∨
key) adjustment clear
13:Multi-step frequency terminal
1
14:Multi-step frequency terminal
2
15:Multi-step frequency terminal
3
16:Multi-step frequency terminal
4
17:Accel/Decel time determinant
1
18:Accel/Decel time determinant
2
1
×
F04.01
Terminal DI2 Function
Selection
51
×
F04.02
Terminal DI3 Function
Selection
52
×
F04.03
Terminal DI4 Function
Selection
52
F04.04
Terminal DI5 Function
Selection
0
F04.05
Terminal DI6 Function
Selection
0
F04.06
Terminal DI7 Function
Selection
0
×
