19:Accel/Decel disabled(ramp
stop not inclusive)
20:Switch to auxiliary speed
setting
21:PLC status reset
22:Simple PLC paused
23:Simple PLC paused
24:PID adjustment direction
25:PID integration paused
26:PID parameter switch
27:Swing frequency
pause(output the
currentfrequency)
28:Swing frequency reset(output
the central frequency)
29:Run command switched to
keypad contro
30:Run command switched to
terminal control
31:Run command switched to
communication control
32:Count input
33:Count clear
34:Length count
35:Length clear
36:DC brake input command at
stop
37～49:reserved
50:Special Machine Enabled
51:Solar Panels Power Enabled
52: Overtank or dry run switch
dormancy
F04.10
Filtering time of digital
input terminal
0.000～1.000s
0.010s
△
F04.11
Delay time of terminal
DI1
0.0～300.0s
0.0s
△
F04.12
Delay time of terminal
DI2
0.0～300.0s
0.0s
△
F04.13
Terminal DI1～DI5
positive/negative logic
DI5、DI4、DI3、DI2、DI1
00000
×
0: Positive logic(Terminals are
on at 0V/off at 24V)
1: Negative Logic (Terminals
are off at 0V/on at 24V)
F04.14
Terminal DI6～AI3
positive/negative logic
AI3、AI2、AI1、DI7、DI6
00000
×
0: Positive logic
1: Negative Logic
F05 Group: Digital Output Terminal
F05.00
Y1 Output Function
Selection
0: No output
1: Drive is running
2: Fault output
3: Frequency-level detection
FDT1 output
4: Frequency-level detection
FDT2 output
5: Drive in 0Hz running 1(no
output at stop)
6: Drive in 0Hz running 2(output
1
×
F05.01
Y2 Output Function
Selection
2
F05.02
Relay R1 Output
Function Selection
30
F05.03
Relay R2 Output
11
×
