Frecon PV Series - Group F13 Process PID

PV series Solar Pumping Inverter
- 32 -
of Inverter Overheat
F11.22
Detectable Level of
load-loss
5.0～100.0%
20.0%
×
F11.23
Detectable Time of
load-loss
0.1～60.0s
5.0s
×
F11.24
Operation selection of
instantaneous power
failure
0：Null
0
×
1：Valid
F11.25
Frequency deceleration
time of instantaneous
power failure
0.0～6000.0s
5.0s
△
F11.26
Selection control of fast
current-limit
0：Prohibit
0
×
1：Permit
F11.27
Auto-Reset Times of
failure
0～20
0
×
F11.28
Auto-Reset Interval of
failure
0.1～100.0s
1.0s
×
F11.29
During the fault
auto-resetting, program
Of switch output
terminal , is action
selection of output fault
0：No action
0
×
1：Action
F11.30
Instantaneous power
off bus voltage
60.0%～Recovery voltage
80.0%
△
F11.31
Instantaneous power off
recovery voltage
Power off voltage～100.0%
85.0%
△
F11.32
Instantaneous power off
voltage detection time
0.01～10.00s
0.10s
△
F11.33
Instantaneous power off
Kp
0.1～100.0%
40.0%
△
F11.34
Instantaneous power off
integration time Ti
0.00 ～ 10.00s （ 0.00 ：
Integration invalid）
0.10s
△
Group F13 Process PID
F13.00
PID setting
0: F13.01 digital setting
0
×
1:keypad potentiometer
2：AI1
3: Communication
4：Multi-Reference
5: DI7/HI pulse input
6: AI2
7：AI3
F13.01
PID digital setting
0.0～100.0%
50.0%
△
F13.02
PID feedback
0：AI1
0
×
1：AI2
2: Communication
