PV series Solar Pumping Inverter
- 25 -
at stop)
7: Upper limit frequency attained
8: Lower limit frequency attained
9: Frequency attained
10: Inverter is ready to work
11: Drive (motor) overloaded
alarm
12: Inverter overheat warning
13: Current running time attained
14: Accumulative power-on time
attained
15: Consecutive running time
attained
16: PLC cycle completed
17: Set count value attained
18: Designated count value
attained
19: Length attained
20: Under load alarm
21:Brake
22~29:reserved
30: Automatic switch of grid
power and solar power
Enabled state of digital
output
Unit's place: Y1
0: Positive logic
1: Negative logic
Decade: Y2 (same as unit's
place)
Hundreds place: Relay 1 output
(same as unit's place)
Thousands place: Relay 2 output
(same as unit's place)
Group F06 Analog and Pulse Input
Minimum input of curve
AI1
0.0%~input of inflection point1
of curve AI1
Set value
corresponding
to minimum input of
curve AI1
Input of inflection point
1 of curve AI1
Minimum input of curve AI1~
Input of inflection point 2 of curve
AI1
Set value
corresponding
to input of inflection
point 1 of curve AI1
Input of inflection point
2 of curve AI1
Input of inflection point 1 of curve
AI1~Maximum input of curve
AI1
Set value
corresponding
to input of inflection
point 2 of curve AI1
Maximum input of curve
AI1
Input of inflection point 2 of curve
AI1~100.0%
