F08.15
Asynchronous Motor
1 field-weakening
coefficient 3
0.0～100.0
70%
×
F08.30
Parameters
Self-identification
0：Null
0
×
1：Asynchronous Motor Static
Self-identification
2：Asynchronous Motor Rotation
Self-identification
F09 Group: Motor 1VF Curve
F09.00
Motor 1VF Curve
Setting
0：Straight Line V/F
0
×
1：Multipoint V/F
2：1.2th power of the V/F curve
3：1.4th power of the V/F curve
4：1.6th power of the V/F curve
5：1.8th power of the V/F curve
6：2.0th power of the V/F curve
7：VF Completed Separation
Mode
8：VF Semi-separation Mode
F09.01
Motor 1 Torque Boost
0.0～30.0% 0.0%：（Auto
Torque Boost）
0.0%
△
F09.02
Motor 1 Cut-off
frequency of
Torque-Boost
0.00～Maximum Frequency
50.00Hz
△
F09.03
Motor 1Multipoint V/F
frequency points 1
0.00～F09.05
0.00Hz
△
F09.04
Motor 1 Multipoint VF
Voltage Points 1
0.0～100.0
0.0%
△
F09.05
Motor 1 Multipoint V/F
frequency points 2
F09.03～F09.05
5.00Hz
△
F09.06
Motor 1 Multipoint VF
Voltage Points 2
0.0～100.0
14.0%
△
F09.07
Motor 1 Multipoint V/F
frequency points 3
F09.05～F09.09
25.00Hz
△
F09.08
Motor 1 Multipoint VF
Voltage Points 3
0.0～100.0
50.0%
△
F09.09
Motor 1 Multipoint V/F
frequency points 4
F09.07～Rated Frequency of
Motor
50.00Hz
△
