Frecon PV Series - F11 Group: Fault and Protection

PV series Solar Pumping Inverter
- 29 -
F09.10
Motor 1 Multipoint VF
Voltage Points 4
0.0～100.0 Ue=100.0%
100.0%
△
F09.11
VF Slip Compensation
Gain
0.0～300.0%
80.0%
△
F09.12
VF Stator Voltage-drop
Compensation Gain
0.0～200.0%
100.0%
△
F09.13
VF Excitation
Compensation Gain
0.0～200.0%
100.0%
△
F09.14
VF Oscillation
Suppression Gain
0.0～300.0%
100.0%
△
F11 Group: Fault and Protection
F11.00
Control of Overcurrent
Stall
0：Null
2
×
1：Overcurrent Stall Mode 1
2: Overcurrent Stall Mode 2
F11.01
Protection current of
Overcurrent Stall
100.0～200.0%
150.0%
×
F11.02
Frequency Fall Time of
Constant Speed
Overcurrent Stall
0.0～6000.0s (Mode 1 is Active）
5.0s
△
F11.03
Overcurrent Stall Mode
2 Proportion Coefficient
0.1～100.0%
3.0%
△
F11.04
Overcurrent Stall Mode
2 Integral Time
0.00～10.00s （0.00：Integral
Invalid）
10.00s
△
F11.05
Control of Overvoltage
Stall
0：Null
0
×
1：Overvoltage Stall Mode 1
2: Overvoltage Stall Mode 2
F11.06
Voltage of Overvoltage
Stall
600～800V
700V
×
F11.07
Overvoltage Stall Mode
2 Proportion Coefficient
0.1～100.0%
3.0%
△
F11.08
Overvoltage Stall Mode
2 Integral Time
0.00～10.00s （0.00：Integral
Invalid）
10.00s
△
