Frecon PV Series - 3.2 H00 Group: Detailed Explanation of Function Code

PV series Solar Pumping Inverter
- 39 -
level of pump
under-load
H00.22
Reset delay time of
pump under-load
0.0～1000.0s
60.0s
△
H00.23
Threshold of
lag-frequency
0.00～200.00Hz
0.30Hz
△
H00.24
Water level direction
detection
0：Positive direction，higher
detection value higher water
level
1
×
1：Negative position，higher
detection value lower water level
H00.25
Weak light voltage
250V～MPPT minimum voltage
300V
×
H00.26
Frequency given mode
0: Maximum frequency
1: Master frequency given mode
0
×
H00.27
Power automatic switch
function
0:disable
1:Enable
0
×
H00.28
Time of automatic
switch to solar power
1～600Min
60Min
△
H00.29
Automatic switch delay
0.1～10.0s
3.0s
△
H00.30
Current power source
in automatic switch
function
0: Grid power
1: Solar power
0
⊙
3.2 H00 Group: Detailed Explanation of Function Code
H00.00
Control of PV Pump
Inverter
0：Null
1
×
1：Valid
0：Null
For standard model
1：Valid
For PV pumps special inverter，H00 Group: Invalid
H00.01
Selection of inverter power
supply
0：Mains
1
×
1：PV Panels
0：Mains
Inverter power supply through the grid, frequency given refer to group of F01, HOO.02～H00.12
invalid.
1：PV Panels
Inverter power supply through solar panels, frequency given mainly through tracking and
adjusting the max power-point PI of solar panels to get. For more details, please refer to H00.02～
H00.12.
