PV series Solar Pumping Inverter
- 6 -
Input specification
PV Input
Maximum Input DC
Voltage
400VDC
Recommended Voc
Range
320～370VDC
Recommended MPPT
Voltage Range
250～350VDC
Starting Voltage
Range
120～400VDC
Grid or backup generator input
Input voltage
Single phase 220V(-15%～30%)
Output specification
Rated output voltage
3PH 220V
Output frequency
0～600.00Hz（default: 0～50.00Hz）
Protection
Built-in Protection
Lighting Protection, over-current, overvoltage, output phase-lose,
under-load, under-voltage, short circuit, overheating, water pump run
dry etc.
1.2.2 Electric specification of AC 380V&DC 540V Input product
Table 1-2 Electric specification of AC 380V&DC 540V Input product
Model No.
Power
Capacity
kVA
Input
Current A
Output
Current A
Adaptive
Motor kW
Size of the
case
PV100-4T-0.7B
1.5
3.4
2.5
0.75
P1-2
PV100-4T-1.5B
3
5.0
4.2
1.5
PV100-4T-2.2B
4
5.8
5.5
2.2
PV100-4T-4.0B
6
11
9.5
3.7、4
PV200-4T-0.7B
1.5
3.4
2.5
0.75
P2-1
PV200-4T-1.5B
3
5.0
4.2
1.5
PV200-4T-2.2B
4
5.8
5.5
2.2
PV200-4T-4.0B
6
11
9.5
3.7、4
P2-2
PV200-4T-5.5B
8.9
14.6
13
5.5
