PV series Solar Pumping Inverter
- 9 -
Model No.
Dimensions and installation size（mm）
kG
W
H
D
W1
W2
H1
H2
H3
H4
d1
d2
P1-1
95
162
120
85
11
151.5
152
110.8
130
4.5
4.5
1.1
P1-2
110
173
135
100
11
163
163
121.8
140.5
4.5
5
1.5
1.3.2 PV200
a: 0.75～15kW Dimensions and wall mounting dimensions
W1
H1
H
W
D
4Xd
Figure 1-3 0.75～15kW Wall Installation Diagram
b: 18.5～200kW Dimensions and installation dimensions
W1
W
H1
H
D
4xd
H
W
D
H1
d W1 W1
Figure 1-4 18.5～30kW Wall Mounting Diagram Figure 1-5 37~200kw Wall Mounting Diagram
