S90-020 M FRICK
®
QUANTUM™ LX COMPRESSOR CONTROL PANEL
Page 32 MAINTENANCE
Maintenance
SCREEN NAME: Maintenance.
ACCESSING:
DESCRIPTION: This screen has been provided to aid the service technician with keeping track of system
maintenance, and can be accessed from the service screen. From here, the service technician can view up
to fifteen (15) user definable maintenance schedules. Each of the schedules may be custom named. This
screen is based upon the Maintenance Schedule that is provided in the IOM manual for the specific
compressor package. For additional information about this screen, refer to S90-021 O (Operation Manual).
System Status…
Maintenance
To Next Page
