S90-020 M FRICK
®
QUANTUM™ LX COMPRESSOR CONTROL PANEL
Page 54 MAINTENANCE
SETPOINTS (Continued)
Drive
Setpoint
Motor Amps
Volts
Service Factor
Horse Power
CT Factor
Name Plate
Recycle Delay
Load Inhibit
Force Unload
Warning
Warning Delay
Shutdown
High Motor Amps
Shutdown Delay
Shutdown
Shutdown Delay
Low Motor Amps
Starting Motor Amps Ignore Period
Maximum Drive Output
Minimum Drive Output
Rate of Increase
Rate of Increase Delay
Rate of Decrease
VFD
Rate of Decrease Delay
The Drive Output will increase or decrease
proportionally with Capacity reaching a maximum
value of ________ at a Capacity of _______ after which
the Drive Output will use the rate of increase
or decrease and cycle time is used.
Capacity will continue to increase or decrease
independently
