FRICK
®
QUANTUM™ LX COMPRESSOR CONTROL PANEL S90-020 M
MAINTENANCE Page 47
SYSTEM STATUS
Trending Setup
Real Time
(Channel)
History
(Channel)
12345678123456 7 8
Capactiy Slide Position
Volume Slide Position
Suction Pressure
Discharge Pressure
Compressor Oil Pressure
Main Oil Injection Pressure
Economizer Pressure
Filter Pressure
Intermediate Pressure
Balance Piston Pressure
System Discharge Pressure
Suction Temperature
Discharge Temperature
Compressor Oil Temperature
Oil Separator Temperature
Process/Brine Temperature Leaving
Process/Brine Temperature Entering
Motor Current
RPM
Auxiliary Analog 1
Auxiliary Analog 2
Auxiliary Analog 3
Auxiliary Analog 4
Auxiliary Analog 5
Auxiliary Analog 6
Auxiliary Analog 7
Auxiliary Analog 8
Auxiliary Analog 9
Auxiliary Analog 10
Auxiliary Analog 11
Auxiliary Analog 12
Auxiliary Analog 13
Auxiliary Analog 14
Auxiliary Analog 15
Auxiliary Analog 16
Auxiliary Analog 17
Auxiliary Analog 18
Auxiliary Analog 19
Auxiliary Analog 20
Compressor Vibration - Suction
Compressor Vibration - Discharge
Motor Vibration - Shaft Side
Motor Vibration - Opposite Shaft Side
None
Real Time Recording Interval ________ Histroy Recording Interval ________
To Next Page
