QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 51
SECTION 6
QUANTUM
™
LX DATA TABLES
The following table shows the three protocol Address ranges that may be utilized for reading/writing data to and from the Quan-
tum™ LX controller; Frick Addresses, Allen-Bradley (AB) Addresses, and Modbus Addresses. This table also shows the Data Table
names, as well as the page numbers within this manual that the pertinent Data Tables may be found:
Frick Address Range AB Address Modbus Address Data Table Pages
100 - 729 N20:100 - N20:729 40101 - 40730 Analog Board Values 52
2000 - 3029 N10:0 - N10:1029 42001-43030 Digital Board Values 53
4017 - 5429 N30:17 - N30:1429 44018 - 45430 Calculated Values 54 – 55
8006 - 16139 N40:6 – N40:8139 48007 - 46140 Mode Values 56 – 68
20300 - 22759 N50:300 - N50:2759 60301 - 62760 Warning/Shutdown Values 69 - 71
24200 - 24889 N60:200 - N60:889 64201 - 64890 Timer Values 72
31900 - 51940
N70:1900 -
N70:21969
71901 - 91970 Setpoint Values 73 - 98
