Frick QUANTUM LX - WARNING;SHUTDOWN MESSAGE LIST

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 69
WARNING/SHUTDOWN VALUES: (Read Only)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Value
Codes
20300-20329 N50:300-N50:329 60301-60330 Control Temperature 1 Sensor Fault (Zones 1 – 30) 2364
20360-20389 N50:360-N50:389 60361-60390 Humidity Sensor Fault (Zones 1 – 30) 2365
20480-20509 N50:481-N50:509 60481-60510 Smoke Detector Shutdown (Zones 1 – 30) 1584
20510-20539 N50:510-N50:539 60511-60540 High Temperature Warning (Zones 1 – 30) 2369
20540-20569 N50:540-N50:569 60541-60570 Low Temperature Warning (Zones 1 – 30) 2370
20570-20599 N50:570-N50:599 60571-60600 High Humidity Warning (Zones 1 – 30) 2371
20600-20629 N50:600-N50:629 60601-60630 Consecutive Defrost Warning (Zones 1 – 30) 2372
20630-20659 N50:630-N50:659 60631-60660 Max Days Between Defrosts Exceeded Warning (Zones 1 – 30) 2373
20660-20689 N50:660-N50:689 60661-60690 Fan Auxiliary Shutdown (Zones 1 – 30) 2374
20720-20749 N50:721-N50:750 60722-60751 Auxiliary Digital Input #1 Warning (Zones 1 – 30) 386
20750-20779 N50:750-N50:779 60751-60780 Auxiliary Digital Input #2 Warning (Zones 1 – 30) 388
20780-20809 N50:780-N50:809 60781-60810 Auxiliary Digital Input #3 Warning (Zones 1 – 30) 390
20810-20839 N50:810-N50:839 60811-60840 Auxiliary Digital Input #4 Warning (Zones 1 – 30) 392
20840-20869 N50:840-N50:869 60841-60870 Auxiliary Digital Input #5 Warning (Zones 1 – 30) 394
20870-20899 N50:870-N50:899 60871-60900 Auxiliary Digital Input #1 Shutdown (Zones 1 – 30) 385
20900-20929 N50:900-N50:929 60901-60930 Auxiliary Digital Input #2 Shutdown (Zones 1 – 30) 387
20930-20959 N50:930-N50:959 60931-60960 Auxiliary Digital Input #3 Shutdown (Zones 1 – 30) 389
20960-20989 N50:960-N50:989 60961-60990 Auxiliary Digital Input #4 Shutdown (Zones 1 – 30) 391
20990-21019 N50:990-N50:1019 60991-61020 Auxiliary Digital Input #5 Shutdown (Zones 1 – 30) 393
21020-21049 N50:1020-N50:1049 61021-61050 Auxiliary Analog Input #1 Low Warning (Zones 1 – 30) 408
21050-21079 N50:1050-N50:1079 61051-61080 Auxiliary Analog Input #2 Low Warning (Zones 1 – 30) 412
21080-21109 N50:1080-N50:1109 61081-61110 Auxiliary Analog Input #3 Low Warning (Zones 1 – 30) 416
21110-21139 N50:1110-N50:1139 61111-61140 Auxiliary Analog Input #4 Low Warning (Zones 1 – 30) 420
21140-21169 N50:140-N50:1169 61141-61170 Auxiliary Analog Input #5 Low Warning (Zones 1 – 30) 424
21170-21199 N50:1170-N50:1199 61171-61200 Auxiliary Analog Input #6 Low Warning (Zones 1 – 30) 428
21200-21229 N50:1200-N50:1229 61201-61230 Auxiliary Analog Input #7 Low Warning (Zones 1 – 30) 432
21230-21259 N50:1230-N50:1259 61231-61260 Auxiliary Analog Input #8 Low Warning (Zones 1 – 30) 436
21260-21289 N50:1260-N50:1289 61261-61290 Auxiliary Analog Input #9 Low Warning (Zones 1 – 30) 440
21290-21319 N50:1290-N50:1319 61291-61320 Auxiliary Analog Input #10 Low Warning (Zones 1 – 30) 444
21320-21349 N50:1320-N50:1349 61321-61350 Auxiliary Analog Input #1 Low Shutdown (Zones 1 – 30) 407
21350-21379 N50:1350-N50:1379 61351-61380 Auxiliary Analog Input #2 Low Shutdown (Zones 1 – 30) 411
21380-21409 N50:1380-N50:1409 21381-21410 Auxiliary Analog Input #3 Low Shutdown (Zones 1 – 30) 415
21410-21439 N50:1410-N50:1439 21411-21440 Auxiliary Analog Input #4 Low Shutdown (Zones 1 – 30) 419
21440-21469 N50:1440-N50:1469 21441-21470 Auxiliary Analog Input #5 Low Shutdown (Zones 1 – 30) 423
21470-21499 N50:1470-N50:1499 21471-21500 Auxiliary Analog Input #6 Low Shutdown (Zones 1 – 30) 427
21500-215029 N50:1500-N50:1529 21501-21530 Auxiliary Analog Input #7 Low Shutdown (Zones 1 – 30) 431
21530-21559 N50:1530-N50:1559 21531-21560 Auxiliary Analog Input #8 Low Shutdown (Zones 1 – 30) 435
21560-21589 N50:1560-N50:1589 21561-21590 Auxiliary Analog Input #9 Low Shutdown (Zones 1 – 30) 439
21590-21619 N50:1590-N50:1619 21591-21620 Auxiliary Analog Input #10 Low Shutdown (Zones 1 – 30) 443
21620-21649 N50:1620-N50:1649 21621-21650 Auxiliary Analog Input #1 High Warning (Zones 1 – 30) 406
21650-21679 N50:1650-N50:1679 21651-21680 Auxiliary Analog Input #2 High Warning (Zones 1 – 30) 410
21680-21709 N50:1680-N50:1709 21681-21710 Auxiliary Analog Input #3 High Warning (Zones 1 – 30) 414
21710-21739 N50:1710-N50:1739 21711-21740 Auxiliary Analog Input #4 High Warning (Zones 1 – 30) 418
