Frick QUANTUM LX - Timer Values

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 72
TIMER VALUES: (Read Only)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
24200-24229 N60:200-N60:229 64201-64230 Fan Cycling Timer - Time Remaining (Zones 1 – 30)
24380-24409 N60:380-N60:409 64381-64410 Defrost Stage Timer - Time Remaining (Zones 1 – 30)
24470-24499 N60:470-N60:499 64471-64500 Cooling Elapsed Time - Time Elapsed (Zones 1 – 30)
24500-24529 N60:500-N60:529 64501-64530 Heating Stage Timer - Time Remaining (Zones 1 – 30)
24620-24649 N60:620-N60:649 64621-64650 Dehumidication Elapsed Time - Time Remaining (Zones 1 – 30)
24860-24889 N60:860-N60:889 64861-64890 Liquid On Elapsed Time - Time Remaining (Zones 1 – 30)
