Frick QUANTUM LX - Setpoint Values

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 73
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
31900-31929 N70:1900-N70:1929 71901-71930
Power Up Time Delay
(Zones 1 - 30)
5 Sec. 0 1,000
31930-31959 N70:1930-N70:1959 71931-71960
Liquid Time To Defrost
(Zones 1 - 30)
200 Min. 0 100,000
31960-31989 N70:1960-N70:1989 71961-71990
Defrost Repeat Warning Time
(Zones 1 - 30)
10 Min. 0 1,000
31990-32019 N70:1990-N70:2019 71991-72020
Defrost Pumpout Time
(Zones 1 - 30)
3 Min. 2 100
32020-32049 N70:2020-N70:2049 72021-72050
Defrost Soft Hot Gas Time
(Zones 1 - 30)
2 Min. 2 100
32050-32079 N70:2050-N70:2079 72051-72080
Defrost Hot Gas Time
(Zones 1 - 30)
20 Min. 2 1,000
32080-32109 N70:2080-N70:2109 72081-72110
Defrost Bleed Time
(Zones 1 - 30)
3 Min. 2 100
32110-32139 N70:2110-N70:2139 72111-72140
Defrost Refreeze Condensate
Time (Zones 1 - 30)
3 Min. 2 100
32140-32169 N70:2140-N70:2169 72141-72170
Defrost Pumpout Variable Fan
Speed (Zones 1 - 30)
60
Percent
%
0 100
32170-32199 N70:2170-N70:2199 72171-72200
Fan Speed High To Low Delay
(Zones 1 - 30)
10 Sec. 0 100
32200-32229 N70:2200-N70:2229 72201-72230
Ammonia Warning Level
(Zones 1 - 30)
100 PPM 0 1,000,000
32260-32289 N70:2260-N70:2289 72261-72290
Heating To Cooling Cycle Mode 1
(Zones 1 - 30)
36 Temp. -20 150
32290-32319 N70:2290-N70:2319 72291-72320
Heating To Cooling Cycle Mode 2
(Zones 1 - 30)
36 Temp. -20 150
32320-32349 N70:2320-N70:2349 72321-72350
Heating To Cooling Cycle Mode 3
(Zones 1 - 30)
36 Temp. -20 150
32350-32379 N70:2350-N70:2379 72351-72380
Heating To Cooling Cycle Mode 4
(Zones 1 - 30)
36 Temp. -20 150
32410-32439 N70:2410-N70:2439 72411-72440
Cooling To Heating Cycle Mode 1
(Zones 1 - 30)
34 Temp. -20 150
32440-32469 N70:2440-N70:2469 72441-72470
Cooling To Heating Cycle Mode 2
(Zones 1 - 30)
34 Temp. -20 150
32470-32499 N70:2470-N70:2499 72471-72500
Cooling To Heating Cycle Mode 3
(Zones 1 - 30)
34 Temp. -20 150
32500-32529 N70:2500-N70:2529 72501-72530
Cooling To Heating Cycle Mode 4
(Zones 1 - 30)
34 Temp. -20 150
32560-32589 N70:2560-N70:2589 72561-72590
Liquid On Temperature Mode 1
(Zones 1 - 30)
40 Temp. -20 150
32590-32619 N70:2590-N70:2619 72591-72620
Liquid On Temperature Mode 2
(Zones 1 - 30)
40 Temp. -20 150
32620-32649 N70:2620-N70:2649 72621-72650
Liquid On Temperature Mode 3
(Zones 1 - 30)
40 Temp. -20 150
32650-32679 N70:2650-N70:2679 72651-72680
Liquid On Temperature Mode 4
(Zones 1 - 30)
40 Temp. -20 150
