QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 74
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
32710-32739 N70:2710-N70:2739 72711-72740
Liquid Off Temperature Mode 1
(Zones 1 - 30)
38 Temp. -20 150
32740-32769 N70:2740-N70:2769 72741-72770
Liquid Off Temperature Mode 2
(Zones 1 - 30)
38 Temp. -20 150
32770-32799 N70:2770-N70:2799 72771-72800
Liquid Off Temperature Mode 3
(Zones 1 - 30)
38 Temp. -20 150
32800-32829 N70:2800-N70:2829 72801-72830
Liquid Off Temperature Mode 4
(Zones 1 - 30)
38 Temp. -20 150
32860-32889 N70:2860-N70:2889 72861-72890
Dehumidication On Percent Mode
1 (Zones 1 - 30)
40
Percent
%
0 100
32890-32919 N70:2890-N70:2919 72891-72920
Dehumidication On Percent Mode
2 (Zones 1 - 30)
40
Percent
%
0 100
32920-32949 N70:2920-N70:2949 72921-72950
Dehumidication On Percent Mode
3 (Zones 1 - 30)
40
Percent
%
0 100
32950-32979 N70:2950-N70:2979 72951-72980
Dehumidication On Percent Mode
4 (Zones 1 - 30)
40
Percent
%
0 100
33010-33039 N70:3010-N70:3039 73011-73040
Dehumidication Off Percent
Mode 1 (Zones 1 - 30)
20
Percent
%
0 100
33040-33069 N70:3040-N70:3069 73041-73070
Dehumidication Off Percent
Mode 2 (Zones 1 - 30)
20
Percent
%
0 100
33070-33099 N70:3070-N70:3099 73071-73100
Dehumidication Off Percent
Mode 3 (Zones 1 - 30)
20
Percent
%
0 100
33100-33129 N70:3100-N70:3129 73101-73130
Dehumidication Off Percent
Mode 4 (Zones 1 - 30)
20
Percent
%
0 100
33160-33189 N70:3160-N70:3189 73161-73190
Fan On Temp. Cool Cycle Mode 1
(Zones 1 - 30)
40 Temp. -20 150
33190-33219 N70:3190-N70:3219 73191-73220
Fan On Temp. Cool Cycle Mode 2
(Zones 1 - 30)
40 Temp. -20 150
33207-33249 N70:3220-N70:3249 73221-73250
Fan On Temp. Cool Cycle Mode 3
(Zones 1 - 30)
40 Temp. -20 150
33250-33279 N70:3250-N70:3279 73251-73280
Fan On Temp. Cool Cycle Mode 4
(Zones 1 - 30)
40 Temp. -20 150
33310-33339 N70:3310-N70:3339 73311-73340
Fan Off Temp. Cool Cycle Mode 1
(Zones 1 - 30)
38 Temp. -20 150
33340-33369 N70:3340-N70:3369 73341-73370
Fan Off Temp. Cool Cycle Mode 2
(Zones 1 - 30)
38 Temp. -20 150
33370-33399 N70:3370-N70:3399 73371-73400
Fan Off Temp. Cool Cycle Mode 3
(Zones 1 - 30)
38 Temp. -20 150
33400-33429 N70:3400-N70:3429 73401-73430
Fan Off Temp. Cool Cycle Mode 4
(Zones 1 - 30)
38 Temp. -20 150
