Frick QUANTUM LX - Page 75

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 75
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
33460-33489 N70:3460-N70:3489 73461-73490
Two Speed Fan High To Low Temp.
Cool Cycle Mode 1 (Zones 1 – 30)
41 Temp. -20 150
33490-33519 N70:3490-N70:3519 73491-73520
Two Speed Fan High To Low Temp.
Cool Cycle Mode 2 (Zones 1 – 30)
41 Temp. -20 150
33520-33549 N70:3520-N70:3549 73521-73550
Two Speed Fan High To Low Temp.
Cool Cycle Mode 3 (Zones 1 – 30)
41 Temp. -20 150
33550-33579 N70:3550-N70:3579 73551-73580
Two Speed Fan High To Low Temp.
Cool Cycle Mode 4 (Zones 1 – 30)
41 Temp. -20 150
33610-33639 N70:3610-N70:3639 73611-73640
Two Speed Fan Low To High
Temperature Cool Cycle Mode 1
(Zones 1 - 30)
42 Temp. -20 150
33640-33669 N70:3640-N70:3669 73641-73670
Two Speed Fan Low To High
Temperature Cool Cycle Mode 2
(Zones 1 - 30)
42 Temp. -20 150
33670-33699 N70:3670-N70:3699 73671-73700
Two Speed Fan Low To High
Temperature Cool Cycle Mode 3
(Zones 1 - 30)
42 Temp. -20 150
33700-33729 N70:3700-N70:3729 73701-73730
Two Speed Fan Low To High
Temperature Cool Cycle Mode 4
(Zones 1 - 30)
42 Temp. -20 150
33760-33789 N70:3760-N70:3789 73761-73790
Dehumidication Variable Speed
Fan Speed Mode 1 (Zones 1 - 30)
60
Percent
%
0 100
33790-33819 N70:3790-N70:3819 73791-73820
Dehumidication Variable Speed
Fan Speed Mode 2 (Zones 1 - 30)
60
Percent
%
0 100
33820-33849 N70:3820-N70:3849 73821-73850
Dehumidication Variable Speed
Fan Speed Mode 4 (Zones 1 - 30)
60
Percent
%
0 100
33850-33879 N70:3850-N70:3879 73851-73880
Dehumidication Variable Speed
Fan Speed Mode 5 (Zones 1 - 30)
60
Percent
%
0 100
33880-33909 N70:3880-N70:3909 73881-73910
Ammonia Warning Delay (Zones
1 - 30)
2 Seconds 0 1,000
33910-33939 N70:3910-N70:3939 73911-73940
Ammonia Shutdown Delay (Zones
1 - 30)
2 Seconds 0 1,000
33940-33969 N70:3940-N70:3969 73941-73970
Smoke Detector Shutdown Delay
(Zones 1 - 30)
5 Seconds 0 1,000
34030-34059 N70:4030-N70:4059 74031-74060
High Humidity Warning Delay
(Zones 1 - 30)
60 Seconds 0 1,000
34120-34149 N70:4120-N70:4149 74121-74150
High Humidity Warning Percent
(Zones 1 - 30)
100
Percent
%
0 100
34150-34179 N70:4150-N70:4179 74151-74180
Maximum Consecutive Defrosts
(Zones 1 - 30)
3 Integer 2 99
34210-34239 N70:4210-N70:4239 74211-74240
Dehumidication Exit Low Tem-
perature Threshold Mode 1 (Zones
1 - 30)
28 Temp. -20 150
34240-34269 N70:4240-N70:4269 74241-74270
Dehumidication Exit Low Tem-
perature Threshold Mode 2 (Zones
1 - 30)
28 Temp. -20 150
