Frick QUANTUM LX - ANALOG BOARD VALUES: (READ ONLY)

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 52
ANALOG BOARD VALUES: (Read Only)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Module
Type
100-129 N20:100-N20:129 40101-40130 Humidity Percent (Zones 1 – 30) Input
130-159 N20:130-N20:159 40131-40160 Ammonia Alarm Sensor (Zones 1 – 30) Input
160-189 N20:160-N20:189 40161-40190 Control Temperature 1 (Zones 1 -30) Input
220-249 N20:220-N20:249 40221-40250 Fan Variable Speed (Zones 1 – 30) Output
250-279 N20:250-N20:279 40251-40280 Liquid Modulating Valve Position (Zones 1 – 30) Output
280-309 N20:280-N20:309 40281-40310 Suction Modulating Valve Position (Zones 1 – 30) Output
310-339 N20:310-N20:339 40311-40340 Auxiliary Analog Output #1 (Zones 1 – 30) Output
340-369 N20:340-N20:369 40341-40370 Auxiliary Analog Output #2 (Zones 1 – 30) Output
370-399 N20:370-N20:399 40371-40400 Auxiliary Analog Output #3 (Zones 1 – 30) Output
400-429 N20:400-N20:429 40401-40430 Auxiliary Analog Output #4 (Zones 1 – 30) Output
430-459 N20:430-N20:459 40431-40460 Auxiliary Analog Input #1 (Zones 1 – 30) Input
460-489 N20:460-N20:489 40461-40490 Auxiliary Analog Input #2 (Zones 1 – 30) Input
490-519 N20:490-N20:519 40491-40520 Auxiliary Analog Input #3 (Zones 1 – 30) Input
520-549 N20:520-N20:549 40521-40550 Auxiliary Analog Input #4 (Zones 1 – 30) Input
550-579 N20:550-N20:579 40551-40580 Auxiliary Analog Input #5 (Zones 1 – 30) Input
580-609 N20:580-N20:609 40581-40610 Auxiliary Analog Input #6 (Zones 1 – 30) Input
610-639 N20:610-N20:639 40611-40640 Auxiliary Analog Input #7 (Zones 1 – 30) Input
640-669 N20:640-N20:669 40641-40670 Auxiliary Analog Input #8 (Zones 1 – 30) Input
670-699 N20:670-N20:699 40671-40700 Auxiliary Analog Input #9 (Zones 1 – 30) Input
700-729 N20:700-N20:729 40701-40730 Auxiliary Analog Input #10 (Zones 1 – 30) Input
