MODE VALUES: (Read Only)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
8006 N40:6 48007 Clear Safeties (All Zones)
R/W
0 = No
1 = Yes
8007 N40:7 48008 Clean Safety History (All Zones)
8008 N40:8 48009 Global Alarm R
0 = None
1 = Warning
2 = Shutdown
8012 N40:2 48013 Ammonia King Valve Shutdown R/W
0 = Disabled
1 = Enabled
8013 N40:13 48014 Global Ammonia Alarm R
0 = None
1 = Warning
2 = Shutdown
8566 N40:566 48567 Communication Units Flag R/W
0 = Celsius, PSIA
1 = Panel Units
8700 -
8729
N40:700-
N40:729
48701 -
48730
Liquid Timer Reset Req. (Zones 1 – 30) R/W
0 = False
1 = True
8760 -
8789
N40:760-
N40:789
48761 -
48790
Current Zone Control (Zones 1 – 30) R
0 = Zone Stand-By
1 = Zone Running
3 = Zone Emergency Shutdown
4 = Zone Shutdown Alarm
5 = Zone Disabled
8790 -
8819
N40:790-
N40:819
48791 -
48820
Current Mode (Zones 1 – 30) R
0 = Mode Stand By
1 = 1
2 = 2
3 = 3
4 = 4
8880 -
8909
N40:880-
N40:909
48881 -
48910
Current Cycle (Zones 1 – 30) R
0 = Cycle Stand By
1 = Cycle Cooling
2 = Cycle Defrost
3 = Cycle Heating
4 = Cycle Dehumidication
8970 -
8999
N40:970-
N40:999
48971 -
49000
Cooling Stage (Zones 1 – 30) R
0 = Cooling Start Up Stage
1 = Cooling Liquid Stage
2 = Cooling Clean Up Stage
9000-
9029
N40:1000-
N40:1029
49001 -
49030
Defrost Stage (Zones 1 – 30) R
0 = Defrost Start Up Stage
1 = Defrost Pumpout Stage
2 = Defrost Soft Hot Gas Stage
3 = Defrost Hot Gas Stage
4 = Defrost Bleed Stage
5 = Defrost Refreeze Condensate Stage
6 = Defrost Clean Up Stage
9030-
9059
N40:1030-
N40:1059
49031 -
49060
Heating Stage (Zones 1 – 30) R
0 = Heating Start Up Stage
1 = Heating Pumpout Stage
2 = Heating Soft Hot Gas Stage
3 = Heating Hot Gas Stage
4 = Heating Bleed Stage
5 = Heating Refreeze Condensate Stage
6 = Heating Clean Up Stage
