QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 55
CALCULATED VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data Value Code
4138 N30:138 44139 Digital Board 9 Port 4 Reset Integer
4139 N30:139 44140 Digital Board 10 Port 4 Reset Integer
4140 N30:140 44141 Digital Board 1 Port 3 Reset Integer
4141 N30:141 44142 Digital Board 2 Port 3 Reset Integer
4142 N30:142 44143 Digital Board 3 Port 3 Reset Integer
4143 N30:143 44144 Digital Board 4 Port 3Reset Integer
4144 N30:144 44145 Digital Board 5 Port 3 Reset Integer
4145 N30:145 44146 Digital Board 6 Port 3 Reset Integer
4146 N30:146 44147 Digital Board 7 Port 3 Reset Integer
4147 N30:147 44148 Digital Board 8 Port 3 Reset Integer
4148 N30:148 44149 Digital Board 9 Port 3 Reset Integer
4149 N30:149 44150 Digital Board 10 Port 3 Reset Integer
4200-4229 N30:200-N30:229 44201-44230 Defrost Last Time (Zones 1 – 30) Seconds
4290-4319 N30:290-N30:319 44291-44320 Defrost Warning Counter (Zones 1 – 30) None
4440-4469 N30:440-N30:469 44441-44470 Liquid On Time (Zones 1 – 30) Minutes
4530-4559 N30:530-N30:559 44531-44560 Oldest Uncleared Safety (Zone 1 – 30) Integer
4560-4589 N30:560-N30:589 44561-44590 Suction Mod. Valve Accumulated Integral (Zones 1 – 30) Real (#.##)
4590-4619 N30:590-N30:619 44591-44620 Liquid Modulating Valve PI Value (Zones 1 -30) Percent%
4620-4649 N30:620-N30:649 44621-44650 Suction Modulating Valve PI Value (Zones 1 – 30) Percent%
4740-4769 N30:740-N30:769 44741-44770 Shutdown Text Index For Email Notication (Zones 1 – 30) Integer
4770-4799 N30:770-N30:799 44771-44800 Fan Variable Accumulated Integral (Zones 1 – 30) Real (#.##)
4800-4829 N30:800-N30:829 44801-44830 Liquid Mod. Valve Accumulated Integral (Zones 1 – 30) Real (#.##)
4830-4859 N30:830-N30:859 44831-44860 Current Safety Number 1 (Zones 1 – 30) Integer
4860-4889 N30:860-N30:889 44861-44890 Current Safety Number 2 (Zones 1 – 30) Integer
4890-4919 N30:890-N30:919 44891-44920 Current Safety Number 3 (Zones 1 – 30) Integer
4920-4949 N30:920-N30:949 44921-44950 Current Safety Number 4 (Zones 1 – 30) Integer
4950-4979 N30:950-N30:979 44951-44980 Current Safety Number 5 (Zones 1 – 30) Integer
4980-5009 N30:980-N30:1009 44981-45010 Current Safety Number 6 (Zones 1 – 30) Integer
5010-5039 N30:1010-N30:1039 45011-45040 Current Safety Number 7 (Zones 1 – 30) Integer
5040-5069 N30:1040-N30:1069 45041-45070 Current Safety Number 8 (Zones 1 – 30) Integer
5070-5099 N30:1070-N30:1099 45071-45100 Current Safety Number 9 (Zones 1 – 30) Integer
5100-5129 N30:1100-N30:1130 45101-45130 Current Safety Number 10 (Zones 1 – 30) Integer
5130-5159 N30:1130-N30-1159 45131-45160 Aux. Analog Out. #1 Accumulated Integral (Zones 1 – 30) Integer
5160-5189 N30:1160-N30:1189 45161-45190 Aux. Analog Output #2 Accumulated Integral (Zones 1 – 30) Integer
5190-5219 N30:1190-N30:1219 45191-45220 Aux. Analog Output #3 Accumulated Integral (Zones 1 – 30) Integer
5220-5249 N30:1220-N30:1249 45221-45250 Aux. Analog Output #4 Accumulated Integral (Zones 1 – 30) Integer
5370-5399 N30:1370-N30:1399 45371-45400 Zone Run Time (Thousands of hours) (Zones 1 – 30) Integer
5400-5429 N30:1400-N30:1429 45401-45430 Zone Run Time (Hours mod 1000) (Zones 1 – 30) Integer
