QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 57
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
9060-
9089
N40:1060 -
N40:1089
49061 -
49090
Stand By Stage (Zones 1 – 30) R
0 = Stand By Start Up Stage
1 = Stand By Suction Stage
2 = Stand By Clean Up Stage
9090-
9119
N40:1090 -
N40:1119
49091 -
49120
Bleed State (Zones 1 – 30) R
0 = Switch Off
1 = Switch On
9120-
9149
N40:1120-
N40:1149
49121-
49150
Fan State (Zones 1 – 30) R
0 = Fan Off
1 = Fan Low
2 = Fan High
9150-
9179
N40:1150-
N40:1179
49151-
49180
Fan Cycling Active (Zones 1 – 30) R
0 = False
1 = True
9180-
9209
N40:1180-
N40:1209
49181-
49210
Hot Gas State (Zones 1 – 30)
R
0 = Switch Off
1 = Switch On
9210-
9239
N40:1210-
N40:1239
49211-
49240
Reheat State (Zones 1 – 30)
9240-
9269
N40:1240-
N40:1269
49241-
49270
Liquid State (Zones 1 – 30)
9270-
9299
N40:1270-
N40:1299
49271-
49300
Soft Hot Gas State (Zones 1 - 30)
9300-
9329
N40:1300-
N40:1329
49301-
49330
Suction State (Zones 1 – 30)
9360-
9389
N40:1360-
N40:1389
49361-
49390
Zone State (Zones 1 – 30) R
0 = Zone Disabled
1 = Zone Enabled
9450-
9479
N40:1450-
N40:1479
49451-
49480
User Requested Mode (Zones 1 – 30) R/W
0 = Mode Stand By
1 = 1
2 = 2
3 = 3
4 = 4
9480-
9509
N40:1480-
N40:1509
49481-
49510
User Requested Defrost (Zones 1 – 30) R/W
0 = False
1 = True
9510-
9539
N40:1510-
N40:1539
49511-
49540
User Req. Defrost Abort (Zones 1 – 30) R/W
9540-
9569
N40:1540-
N40:1569
49541-
49570
Cycle Status (Zones 1 – 30) R
0 = Satised
1 = Active
9570-
9599
N40:1570-
N40:1599
49571-
49600
Defrost Initiator (Zones 1 – 30) R
0 = Defrost Inactive
1 = Defrost Scheduled
2 = Defrost Liquid Timer
3 = Defrost Digital Input
4 = Defrost User Request
9600-
9629
N40:1600-
N40:1629
49601-
49630
Defrosts by Digital Input Enabled (Zones 1 – 30) R
0 = False
1 = True
9630 -
9659
N40:1630 -
N40:1659
49631-
49660
Defrost Source (Zones 1 – 30) R
0 = None
1 = Schedule
2 = Liquid Timer
3 = Scheduled Liquid Override
9690 -
9719
N40:1690 -
N40:1719
49691-
49720
Defrost Pumpout Two Speed Fan Speed (Zones
1 – 30)
R
0 = Fan Off
1 = Fan Low
2 = Fan High
To Next Page
