QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 58
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
9720 -
9749
N40:1720 -
N40:1749
49721-
49750
Dehumidication Stage (Zones 1 – 30) R
0 = Dehumidication Start Up Stage
1 = Dehumidication Liquid Stage
2 = Dehumidication Clean Up Stage
9780 -
9809
N40:1780 -
N40:1809
49781 -
49810
Humidity Sensor Conguration Status
(Zones 1 – 30)
R
0 = Disabled
1 = Enabled
9810 -
9839
N40:1810 -
N40:1839
49811 -
49840
Group Association (Zones 1 – 30) R
0 = Group A
1 = Group B
2 = Group C
3 = Group D
4 = Group E
5 = Group F
6 = Group G
7 = Group H
8 = Group I
9 = Group J
99 = None
10020 -
10049
N40:2020 -
N40:2049
50021 -
50050
Fan Type (Zones 1 – 30) R
0 = Not Available
1 = Single Speed
2 = Two Speed Type I
3 = Two Speed Type II
4 = Variable Speed
10110 -
10139
N40:2110 -
N40:2139
50110 -
50139
Clear Safeties (Zones 1 – 30) R/W
0 = No
1 = Yes
10170 -
10199
N40:2170 -
N40:2199
50170 -
50199
Clear Safety History (Zones 1 – 30) R/W
0 = No
1 = Yes
