Frick QUANTUM LX - Page 59

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 59
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
10290-10319
N40:2290 -
N40:2319
50290-50319 Defrost Cycle Enabled Mode 1 (Zones 1 – 30)
R
0 = Disabled
1 = Enabled
10320-10349
N40:2320 -
N40:2349
50320-50349 Defrost Cycle Enabled Mode 2 (Zones 1 – 30)
10350-10379
N40:2350 -
N40:2379
50350-50379 Defrost Cycle Enabled Mode 3 (Zones 1 – 30)
10380-10409
N40:2380 -
N40:2409
50380-50409 Defrost Cycle Enabled Mode 4 (Zones 1 – 30)
10410-10439
N40:2410-
N40:2439
50410-50439 Defrost Cycle Enabled Mode 5 (Zones 1 -30)
10440-10469
N40:2440-
N40:2469
50440-50469 Cooling Cycle Enabled Mode 1 (Zones 1 – 30)
10470-10499
N40:2470-
N40:2499
50470-50499 Cooling Cycle Enabled Mode 2 (Zones 1 – 30)
10500-10529
N40:2500-
N40:2529
50500-50529 Cooling Cycle Enabled Mode 3 (Zones 1 – 30)
10530-10559
N40:2530-
N40:2559
50530-50559 Cooling Cycle Enabled Mode 4 (Zones 1 – 30)
10560-10589
N40:2560-
N40:2589
50560-50589 Cooling Cycle Enabled Mode 5 (Zones 1 – 30)
10590-10619
N40:2590-
N40:2619
50590-50619 Heating Cycle Enabled Mode 1 (Zones 1 – 30)
10620-10649
N40:2620-
N40:2649
50620-50649 Heating Cycle Enabled Mode 2 (Zones 1 – 30)
10650-10679
N40:2650-
N40:2679
50650-50679 Heating Cycle Enabled Mode 3 (Zones 1 – 30)
10680-10709
N40:2680-
N40:2709
50680-50709 Heating Cycle Enabled Mode 4 (Zones 1 – 30)
10710-10739
N40:2710-
N40:2739
50710-50739 Heating Cycle Enabled Mode 5 (Zones 1 – 30)
10740-10769
N40:2740-
N40:2769
50740-50769 Dehumidication Cycle Enabled Mode 1 (Zones 1 – 30)
10770-10799
N40:2770-
N40:2799
50770-50799 Dehumidication Cycle Enabled Mode 2 (Zones 1 – 30)
10800-10829
N40:2800-
N40:2829
50800-50829 Dehumidication Cycle Enabled Mode 3 (Zones 1 – 30)
10830-10859
N40:2830-
N40:2859
50831-50860 Dehumidication Cycle Enabled Mode 4 (Zones 1 – 30)
10860-10889
N40:2860
N40:2889
50861-50890 Dehumidication Cycle Enabled Mode 5 (Zones 1 – 30)
11040-11069
N40:2940-
N40:2969
51041-51070
Dehumidication Two Speed Fan Speed Mode 1
(Zones 1 – 30)
R
0 = Fan Off
1 = Fan Low
2 = Fan High
11070-11099
N40:2970-
N40:2999
51071-51100
Dehumidication Two Speed Fan Speed Mode 2
(Zones 1 – 30)
11100-11129
N40:3000-
N40:3029
51101-51130
Dehumidication Two Speed Fan Speed Mode 3
(Zones 1 – 30)
11130-11159
N40:3030-
N40:3059
51131-51160
Dehumidication Two Speed Fan Speed Mode 4
(Zones 1 – 30)
11160-11189
N40:3060-
N40:3089
51161-51190
Dehumidication Two Speed Fan Speed Mode 5
(Zones 1 – 30)
