QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 60
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
11190-
11219
N40:3090-
N40:3119
51191-51220
Fan Cycling Function Enabled Cool Cycle Mode 1
(Zones 1 – 30)
R
0 = False
1 = True
11220-
11249
N40:3120-
N40:3149
51221-51250
Fan Cycling Function Enabled Cool Cycle Mode 2
(Zones 1 – 30)
11250-
11279
N40:3150-
N40:3179
51251-51280
Fan Cycling Function Enabled Cool Cycle Mode 3
(Zones 1 – 30)
11280-
11309
N40:3180-
N40:3209
51281-51310
Fan Cycling Function Enabled Cool Cycle Mode 4
(Zones 1 – 30)
11310-
11339
N40:3210-
N40:3239
51311-51340
Fan Cycling Function Enabled Cool Cycle Mode 5
(Zones 1 – 30)
11490-
11519
N40:3290-
N40:3319
51491-51520
Heating Pumpout Two Speed Fan Speed (Zones
1 – 30)
R
0 = Fan Off
1 = Fan Low
2 = Fan High
11520-
11549
N40:3320-
N40:3349
51521-51550 Ammonia Alarm A Mapping (Zones 1 – 30)
R
0 = None
1 = Ammonia Alarm 1
2 = Ammonia Alarm 2
3 = Ammonia Alarm 3
4 = Ammonia Alarm 4
5 = Ammonia Alarm 5
6 = Ammonia Alarm 6
7 = Ammonia Alarm 7
8 = Ammonia Alarm 8
9 = Ammonia Alarm 9
10 = Ammonia Alarm 10
11 = Ammonia Alarm 11
12 = Ammonia Alarm 12
13 = Ammonia Alarm 13
14 = Ammonia Alarm 14
15 = Ammonia Alarm 15
16 = Ammonia Alarm 16
17 = Ammonia Alarm 17
18 = Ammonia Alarm 18
19 = Ammonia Alarm 19
20 = Ammonia Alarm 20
21 = Ammonia Alarm 21
22 = Ammonia Alarm 22
23 = Ammonia Alarm 23
24 = Ammonia Alarm 24
25 = Ammonia Alarm 25
26 = Ammonia Alarm 26
27 = Ammonia Alarm 27
28 = Ammonia Alarm 28
29 = Ammonia Alarm 29
30 = Ammonia Alarm 30
11550-
11579
N40:3550-
N40:3579
51551-51580 Ammonia Alarm B Mapping (Zones 1 – 30)
11580-
11609
N40:3580-
N40:3609
51581-51610 Ammonia Alarm C Mapping (Zones 1 – 30)
11610-
11639
N40:3610-
N40:3639
51611-51640 Ammonia Alarm D Mapping (Zone 1 – 30)
