Frick QUANTUM LX - Page 61

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 61
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
11640-
11669
N40:3640-
N40:3669
51641-51670
Cooling Suction Coupling (Zones 1 –
30)
R
0 = Cooling Suction Always
1 = Cooling Bound Suction
2 = Cooling Suction Always Except Off
11670-
11699
N40:3670-
N40:3699
51671-51700 Defrost Abort Step (Zones 1 – 30) R/W
0 = False
1 = True
11880-
11909
N40:3880-
N40:3909
51881-51910
Auxiliary Digital Input #1 Alarm Con-
guration (Zones 1 – 30)
R
0 = Auxiliary Input Disable
1 = Aux. Input Shutdown When Running
2 = Aux. Input Shutdown Always
3 = Aux. Input Warning When Running
4 = Aux. Input Warning Always
11910-
11939
N40:3910-
N40:3939
51911-51940
Auxiliary Digital Input #2 Alarm Con-
guration (Zones 1 – 30)
11940-
11969
N40:3940-
N40:3969
51941-51970
Auxiliary Digital Input #3 Alarm Con-
guration (Zones 1 – 30)
11970-
11999
N40:3970-
N40:3999
51971-52000
Auxiliary Digital Input #4 Alarm Con-
guration (Zones 1 – 30)
12000-
12029
N40:4000-
N40:4029
52001-52030
Auxiliary Digital Input #5 Alarm Con-
guration (Zones 1 – 30)
12030-
12059
N40:4030-
N40:4059
52031-52060
Fan Cycling Function Enabled, Heat
Cycle Mode 1 (Zones 1 – 30)
R
0 = False
1 = True
12060-
12089
N40:4060-
N40:4089
52061-52090
Fan Cycling Function Enabled, Heat
Cycle Mode 2 (Zones 1 – 30)
12090-
12119
N40:4090-
N40:4119
52091-52120
Fan Cycling Function Enabled, Heat
Cycle Mode 3 (Zones 1 – 30)
12120-
12149
N40:4120-
N40:4149
52121-52150
Fan Cycling Function Enabled, Heat
Cycle Mode 3 (Zones 1 -30)
12150-
12279
N40:4150-
N40:4279
52151-52280
Fan Cycling Function Enabled, Heat
Cycle Mode 5 (Zones 1 – 30)
12180-
12209
N40:4180-
N40:4209
52181-52210
Fan Auxiliary Conguration State
(Zones 1 – 30)
R
0 = Disabled
1 = Enabled
0 = Mode Stand By
1 = Mode 1
2 = Mode 2
3 = Mode 3
4 = Mode 4
12210-
12239
N40:4210-
N40:4239
52211-52240 Sunday Schedule 1 (Zones 1 – 30)
12240-
12269
N40:4240-
N40:4269
52241-52270 Sunday Schedule 2 (Zones 1 – 30)
12270-
12299
N40:4270-
N40:4299
52271-52300 Sunday Schedule 3 (Zones 1 – 30)
12300-
12329
N40:4300-
N40:4329
52301-52330 Sunday Schedule 4 (Zones 1 – 30)
12330-
12359
N40:4330-
N40:4359
52331-52360 Sunday Schedule 5 (Zones 1 – 30)
12360-
12389
N40:4360-
N40:4389
52361-52390 Sunday Schedule 6 (Zones 1 – 30)
12390-
12419
N40:4390-
N40:4419
52391-52420 Sunday Schedule 7 (Zones 1 – 30)
12420-
12449
N40:4420-
N40:4449
52421-52450 Sunday Schedule 8 (Zones 1 – 30)
